Higer Bus KLQ6138DF+Dongfeng Cummins L360 20
higer121404
higer121404 higer121405 higer121406

Technical Parameter

Length(mm) 12500
Width(mm) 2550
Height(mm) 3800
G.V.W.(kg) 21500
Max.Speed(km/h) 120
Wheelbase(mm) 5500/1300
Max.Grade Ability(%) 30
Seats 57+1(2+2 layout)/71+1(3+2 layout)
Fuel Consumption(l/100km) 24
Fuel Tank (l) 400
Engine Model Dongfeng Cummins L360 20
Engine Output (kw/rpm) 264/2200
Engine Max. Torque (N.m/rpm) 1400/1300-1500
Chassis Clutch diaphragm spring clutch
Chassis Suspension System multiple leaf spring&air suspension
Chassis Gearbox Qijiang S6-100
Chassis Braking System dual-circuilt service braking, energy storge spring braking system; retarder
Chassis Steering System right hand drive;intergral power steering gear
Front Axle 7T front axle, 13T
Rear Axle 5.5t tag axle
Tyre 315/80 R22.5 tubeless tyre
Model Intercity Bus
Energy Diesel

Product Details

Higer Bus KLQ6138DF+Dongfeng Cummins L360 20
