Position:buses > 12m-13m > Ankai Bus HFF6121GZ-4
Ankai Bus HFF6121GZ-4
Ankai Bus HFF6121GZ-4 Ankai Bus HFF6121GZ-4 Ankai Bus HFF6121GZ-4 Ankai Bus HFF6121GZ-4
Ankai Bus HFF6121GZ-4

Model:
City Bus

Seats:
31-40seats

Dimensions(mm):
12000 2550 3150/3250

Add to Favorites>>

Technical Parameter

Dimensions(mm) 12000 2550 3150/3250
G.V.W.(kg) 17500
Max.Speed(km/h) 69
Approach Angle/Departure Angle(°) 7°/7°
Wheelbase(mm) 6100
Seats 32+1
Fuel Tank (l) 220
Engine Model YC6G270-30/YC6G270-20/C260 20
Engine Output (kw/rpm) 199/2000;199/2200;191/2200
Engine Max. Torque (N.m/rpm) 1080/1400-1600; 1025/1300
Chassis Clutch φ430
Chassis Suspension System Leaf Spring Front 4/Rear 5
Chassis Gearbox QJ1205
Chassis Braking System Dual-circuit Air Brake
Chassis Steering System Domestic
Front Axle AK153 Front Axle
Rear Axle AK437 Rear Axle
Tyre 11R22.5-GITI
Length 12m-13m
Seats 31-40seats
Model City Bus
