Hengtong Bus CKZ6801H3

Technical Parameter

Dimensions（mm）	8000×2330×2950(3050)
G.V.W.（kg）	9770
Wheelbase（mm）	3800
Max.Grade Ability（%）	≥20
Seats	22+1, Adjustable Driver Seat, 420B Plastic Passenger Seat.
Fuel Tank (L)	110
Engine Model	YC4E160-30
Engine Output (kw/rpm)	118
Engine Max. torque (N.m/rpm)	600
Chassis Model	EQ6761H3AC
Chassis Clutch	Single Dry Plate, Diaphragm Spring， Hydraulic Air Assisting Control
Chassis Suspension System	F 3/R 4 Less Leaf Spring, Double Shock Absorber.
Chassis Gearbox	5 Speed, Soft Shaft Control
Chassis Braking System	Double Circuit Pneumatic Brake System with Drum Brae, Energy Storage Spring Parking Brake.
Length	8m-9m
Seats	21-30seats
Model	City bus

Introduction

New Sunshine series ranges from 7.5meters to 8.5meters.

It is the latest economic solution for developing or small city’s medium volume urban passenger transport.

By specialized front and rear axle and full rivet frame, the larger capacity is achieved. Internal noise reduced by 8% while optimal design reducing weight by 2% by used silencing material.
