| CHASSIS | |
| Engine | YC6G270-20,YC6G240-30,YC6G270-30(EURO
III),JO8C UF, C245 20, ISBE250 30(EURO III) |
| Clutch: | Diaphragm
spring clutch(430)/ Hydraulic clutch |
| Transmission | hangchi
gearbox/ ZF 5HP502 Auto transmission |
| Suspension | Leaf
spring suspension / air bellows supension with front/rear stabilizer bar |
| Axle | front
and rear axle |
| Steering | power
steering gearbox/ZF steering gearbox |
| Braking | Front
/rear drum braker;dual circuit air braking system ;Parking brake acting on rear
axle |
| Tyre: | 11R22.5
tubeless tyre |
| Others | Auto
slack adjustor; ABS/WABCO ABS*; electric/integration retarder*; automatic chassis
lubrication system* |
| BODY | |
| A/C | Higer
roof mounted dependent A/C(BOCK compressor,25.6KW) with ventilation, air filtrating
funtion |
| Heater | Front
windshield defroster,independent heater* |
| Seats | Standard
seats (high backret without adjustable function)/ adjustable function
High
backrest and full adjustable function driver seat |
| Door | Front
pneumatic out-swing door;auto flexiable step* |
| Windows | Sealed
side windows( driver window and rear side window is sliding style) |
| Lighting | Inner
strip ceiling light; reader lamps; step lamps; high position brake lamp |
| Electrical
system | Battery:2*200Ah,Generator:
2*28V/150A ,audio system,video system with CRT/LCD* monitor, SIMENS VDR*, Auto
extinguisher* |
| Others | Spary
plastic fence ;aluminium luggage cabin door;digital clock;DUPONT painting; |
| SPECIFICATION |
| Standard
seat number | 41+1+1 |
| Overall
dimensions(mm) | 10490X2500X3590 |
| Rated
passenger | 24~47 |
| Max.
Speed(Km/h) | 120/105 |
| Kerb
Mass/GVW(kg) | 11200/14900 |
| Fuel
tank(L) | 400 |
| Entry
height(mm) | 400 |
| Central
aisle height(mm) | 2050 |
