| Length(mm) | 11990 |
| Width(mm) | 2540 |
| Height(mm) | 3280 |
| G.V.W.（kg） | 18000 |
| Max.Speed(km/h) | 69 |
| Wheelbase（mm） | 6100 |
| Model | City Bus |
| Energy | EV |
| Overall Specification | ||
| Overall dimension（mm） | 11990 | |
| Overall width（mm） | 2540 | |
| Overall height（mm） | 3280 | |
| Body inside height（mm） | 2450 | |
| Wheel base（mm） | 6100 | |
| Front/rear overhang（mm） | 2640/3250 | |
| Approach/departure（º） | 7/7 | |
| First Step Height(mm) | ≤360 | |
| Max G.V.W. (kg) | 18000 | |
| Seats capacity | 32+1 | |
| Max. speed （km/h） | 69 | |
| Control systerm | Vehicle control unit | |
| Battery | ||
| Power Battery | lithium-ion battery | |
| Capacity | 400AH | |
| Rated power (kw) | 80 | |
| Rated power(KW) | 160 | |
| Max torque(Nm) | 477 | |
| Max torque(Nm) | 1000 | |
| cruising range(Km) | 414 | |
| Manufacturer | China first brand, | |
| Chassis | ||
| Manufacturer | Zhontong Bus Holding Co., Ltd | |
| Front axle | 7.5ton | |
| Rear axle | 13ton | |
| Suspension | Air suspension, Front 2 rear 4 | |
| Steering | Electro Power Steering | |
| Brake | Dual-circuit air brake, Front disc and rear drum brake, ABS | |
| Tire | 275/70R22.5×6 | |
| Battery | 120A.h×2 | |
| Others | Air dryer, Speed limiting device, | |
| Body | ||
| Door | inner swinging, Front 1double and rear 1double | |
| Seats | Driver seat:ZTZY1021, Passenger seat:ZTZY8061, replaceable cover | |
