Technical Parameter
| Dimensions（mm） |
10680×2500×3580 |
| G.V.W.（kg） |
14750 |
| Wheelbase（mm） |
5170 |
| Seats |
47+1+1 |
| Fuel Consumption(L/100km) |
23 |
| Fuel Tank (L) |
380 |
| Engine Model |
WD615.30 (Diesel)， YC6A240-20 (Diesel) |
| Engine Output (kw/rpm) |
221kW(300PS)/2200rpm |
| Engine Max. torque (N.m/rpm) |
1160N·m/1100-1600rpm |
| Chassis Clutch |
Single-plate, dry type |
| Chassis Suspension System |
Leaf spring |
| Chassis Gearbox |
6 speed, manual |
| Chassis Braking System |
Dual circuit pneumatic drum brake, energy storage spring parking system, ABS & automatic clearance adjust arm |
| Length |
10m-11m |
| Seats |
41-50seats |
| Model |
Tourism |
