Position:buses > 11m-12m > Zhongtong Bus LCK6122EVG Electric Bus
Zhongtong Bus LCK6122EVG Electric Bus
LCK6122EVG-02 LCK6122EVG-03 LCK6122EVG-04
Zhongtong Bus LCK6122EVG Electric Bus

Model:
City Bus

Seats:
31-40seats

Dimensions(mm):
11990*2540*3280

Add to Favorites>>

Technical Parameter

Dimensions(mm) 11990*2540*3280
G.V.W.(kg) 18000
Max.Speed(km/h) 69
Wheelbase(mm) 6100
Length 11m-12m
Seats 31-40seats
Model City Bus
Energy EV

Product Details

Overall Specification
Overall dimension(mm) 11990
Overall width(mm) 2540
Overall height(mm) 3280
Body inside height(mm) 2450
Wheel base(mm) 6100
Front/rear overhang(mm) 2640/3250
Approach/departure(º) 7/7
First Step Height(mm) ≤360
Max G.V.W. (kg) 18000
Seats capacity 32+1
Max. speed  (km/h) 69
Control systerm Vehicle control unit
                                                                              Battery
Power Battery  lithium-ion battery
Capacity 400AH
Rated power (kw) 80
Rated power(KW) 160
Max torque(Nm) 477
Max torque(Nm) 1000
cruising range(Km) 414
Manufacturer China first brand,
Chassis
Manufacturer Zhontong Bus Holding Co., Ltd
Front axle 7.5ton
Rear axle 13ton
Suspension Air suspension, Front 2 rear 4
Steering Electro Power Steering
Brake Dual-circuit air brake,  Front disc and rear drum brake, ABS
Tire 275/70R22.5×6
Battery 120A.h×2
Others Air dryer, Speed limiting device,
Body
Door inner swinging, Front 1double and rear 1double
Seats Driver seat:ZTZY1021, Passenger seat:ZTZY8061, replaceable cover
