Position:buses > 12m-13m > Wuzhoulong Bus FDG6128CNG
Wuzhoulong Bus FDG6128CNG
Wuzhoulong Bus FDG6128CNG Wuzhoulong Bus FDG6128CNG
Wuzhoulong Bus FDG6128CNG

Model:
Tourism

Seats:
41-50seats

Dimensions(mm):
11990X2550X3850

Add to Favorites>>

Technical Parameter

Dimensions(mm) 11990X2550X3850
G.V.W.(kg) 18,000
Max.Speed(km/h) 115
Approach Angle/Departure Angle(°) 9°/8.5°
Wheelbase(mm) 6,000
Seats 49+1+1
Luggage Capacity(m3 5.5
Engine Model Shangchai SC9DT320Q3
Engine Output (kw/rpm) 320/2200
Engine Max. Torque (N.m/rpm) 1250/1300-1400
Chassis Clutch φ430 velum spring clutch
Chassis Suspension System air suspension 2/4
Chassis Gearbox QJ1506 6speed mannual transmission
Chassis Braking System Dual circuit air brake with ECE standard,Chinese retarder
Chassis Steering System Integral power steering
Front Axle Dong feng DANA front axle,disc type brake
Rear Axle Dong feng DANA axle,drum type brake
Energy Storage System/Battery 180A.h×2/150A 28V×2
Tyre 295/80R22.5 Bridgestone
Other Facilities Chinese ABS Auto-ajusting arm
Length 12m-13m
Seats 41-50seats
Model Tourism
Energy Natural Gas
